We don't regulary think about it but the garage door openers operates the largest moving part of your home on a pretty frequent basis. The motor doesn't lift the door its the leverage system created by the springs, cables and counterbalances. The motor initiates the lifting motion, therefore it doesn't have to be extremely powerful to lift most doors. Here is a run down on a few types of garage door openers.
For decades, homeowners interested in automating their garage doors had three choices: chain-, belt- or screw-driven openers. That has changed with the introduction of residential jackshaft and direct-drive models. Some of the conventional wisdom about the three standard options has changed, too.
Standard Garage Door Openers
Craftsman Chain Driven Garage Door Opener
Chain-driven models include a chain—similar to a bicycle chain—that pushes or pulls a trolley (carriage) that connects to a metal bar, called a J-arm, that is affixed to the garage door. If your garage is situated under a bedroom, the noise generated by metal-to-metal contact and vibration may be a nuisance. If the garage is detached, it probably isn’t. Newer chain-driven units with DC motors and soft start-and-stop technology are significantly quieter than older units.
Belt-driven openers are similar in design to chain-driven models, except a reinforced belt is what pushes or pulls the trolley. The belts may be made of fiberglass, polyurethane, or steel-reinforced rubber. Belt-driven openers are just as reliable as chain-driven openers but quieter. The negative for belt-driven openers is that they cost about $30 to $60 more than chain-driven units.
Related: Product Showcase: Garage Doors
With screw-driven openers, the trolley rides on a threaded-steel rod as a motor rotates the rod. Because this design has fewer moving parts, manufacturers claim that it requires less maintenance than other systems. Screw-driven openers, however, have run into trouble in regions that have large swings in temperature from summer to winter. In addition, they are noisier than belt-driven openers. That said, manufacturers of screw-driven openers have recently made improvements with regard to temperature sensitivity and noise. In addition, screw-driven openers are among speediest these days as well, opening a door at 10- to 12-in. per second compared to the standard 6- to 8-in. per second. (For safety, all garage door openers close doors at a slower 7-in. per second.)
Jackshaft and Direct-Drive Garage Door Openers
Raynor's Prodigy Wall-Mounted Jackshaft Garage Door Opener
Jackshaft openers, unlike the other systems, mount on the wall beside the garage door. A 24-v DC motor drives pulleys and cables that turn the torsion bar and raise the garage door. When the motor is reversed, cable tension is loosened and the door lowers. This system is reliable and quiet. In addition, it keeps the ceiling free for overhead storage and is well-suited to garages with high or low ceilings. Jackshaft openers are more expensive than most other types of openers.
Read The Entire Article Here: Garage Door Openers 101
.
Direct-drive units are claimed to be the quietest of all garage door units, because there is only one moving part—the motor. Developed and manufactured in Germany, the motor (not a trolley) travels along a stationary chain that is embedded in an overhead rail. A J-arm links the moving motor to the door. Direct-drive units cost about the same as belt-driven units and come with lifetime warranties.
.
Direct-drive units are claimed to be the quietest of all garage door units, because there is only one moving part—the motor. Developed and manufactured in Germany, the motor (not a trolley) travels along a stationary chain that is embedded in an overhead rail. A J-arm links the moving motor to the door. Direct-drive units cost about the same as belt-driven units and come with lifetime warranties.
The springs are what stores most of the power (torque) and therefore makes them potentially dangerous. Thererfore, do-it-yourselfers shoulddefer to the professionals before tackling this type of job. Another resource is to consult your owners manual. There will contain information about type of lubricants that is suitable for the components of your garage door. These steps will help maintain the longevity of your garage door. Garage door openers now days offer many different options, and features such as blue tooth connectivity, smart phone operation with remote lockout, fingerprint sensors and motion sensor lighting.
